Bell X-22A Quad-Tilt-Duct VTOL Research Aircraft Family
The Bell X-22A was a U.S. Navy-sponsored VTOL research aircraft with four tilting ducted propellers arranged in tandem pairs. The ducts rotated from vertical lift to forward flight, while variable-stability instrumentation let researchers study hover, transition and control of future V/STOL transports. Two aircraft were built, and the surviving research lineage remained useful long after the first prototype was lost.
Follow this vehicle family
Future launches and major activity directly linked to this vehicle family.
Identity
- Aliases
- Bell X-22X-22ABell Model D2127Quad Tilt-Duct
- Family Name
- Bell X-22A
- Full Name
- Bell X-22A Quad-Tilt-Duct VTOL Research Aircraft Family
- Roles
- militaryexperimentalresearchtechnology_demonstrator
- Status
- retired
- Type
- aircraft
Details
- Aircraft Specs
- Configuration
- powered_lift
- Operating Modes
- land
- Takeoff Landing Capabilities
- vtol
- Description
- The Bell X-22A was a U.S. Navy-sponsored VTOL research aircraft with four tilting ducted propellers arranged in tandem pairs. The ducts rotated from vertical lift to forward flight, while variable-stability instrumentation let researchers study hover, transition and control of future V/STOL transports. Two aircraft were built, and the surviving research lineage remained useful long after the first prototype was lost.
- First Flight Year
- 1,966
