Boeing C-17 Globemaster III Family
The Boeing C-17 Globemaster III is a four-engine strategic and tactical airlifter designed to move large cargo, personnel, and medical patients between long-range routes and short, austere airfields. Its high-lift wing, externally blown flaps, reversible thrust, wide cargo hold, and rear loading ramp support rapid transport, humanitarian relief, aeromedical evacuation, and global air mobility for the United States and international operators.
Follow this vehicle family
Future launches and major activity directly linked to this vehicle family.
Identity
- Aliases
- C-17C-17AC-17 Globemaster IIIGlobemaster III
- Family Name
- Boeing C-17 Globemaster III
- Full Name
- Boeing C-17 Globemaster III Family
- Roles
- cargomilitaryutilityair_ambulance
- Status
- active
- Type
- aircraft
Details
- Aircraft Specs
- Configuration
- fixed_wing
- Crew Capacity
- 3
- Max Payload Mass Kg
- 77,519
- Max Speed Kph
- 833.4
- Max Takeoff Mass Kg
- 265,352
- Operating Modes
- land
- Range Km
- 4,445
- Service Ceiling M
- 13,716
- Takeoff Landing Capabilities
- stol
- Description
- The Boeing C-17 Globemaster III is a four-engine strategic and tactical airlifter designed to move large cargo, personnel, and medical patients between long-range routes and short, austere airfields. Its high-lift wing, externally blown flaps, reversible thrust, wide cargo hold, and rear loading ramp support rapid transport, humanitarian relief, aeromedical evacuation, and global air mobility for the United States and international operators.
- Dimensions
- Height M
- 16.79
- Length M
- 53
- Wingspan M
- 51.75
- First Flight Year
- 1,991
- Manufacturer
- Propulsion Configurations
- Entries
- Count
- 4
- Placement
- nacelle
- Propulsion System
- Role
- main
- Stage
- airframe
- Variant Notes
- Four exact F117-PW-100 turbofans, one in each wing nacelle; each is rated at 40,440 pounds of thrust.
- Name
- C-17 F117-PW-100 installation
- Notes
- The Boeing C-17 Globemaster III uses four exact Pratt & Whitney F117-PW-100 turbofans. Boeing also presents the commercial PW2040 designation; the installation relationship uses the exact military model named by the Air Force and Pratt & Whitney.
