Delta IV Medium+ (4,2)
Delta IV Medium+ (4,2) paired one Common Booster Core with two GEM 60 solid motors, a four-metre cryogenic upper stage, and a four-metre payload fairing. It was the most-flown Medium configuration, completing 15 successful missions from the inaugural Delta IV launch in 2002 through the final Medium flight in 2019.
Identity
- Aliases
- Delta IV M+(4,2)Delta IV Medium Plus 4,2Delta 4 Medium+ (4,2)
- Family Name
- Delta IV Medium+
- Full Name
- Delta IV Medium+ (4,2)
- Reusability
- expendable
- Slug
- delta-iv-medium-plus-4-2
- Status
- retired
- Type
- rocket
- Variant Name
- (4,2)
Details
- Description
- Delta IV Medium+ (4,2) paired one Common Booster Core with two GEM 60 solid motors, a four-metre cryogenic upper stage, and a four-metre payload fairing. It was the most-flown Medium configuration, completing 15 successful missions from the inaugural Delta IV launch in 2002 through the final Medium flight in 2019.
- Diameter M
- 5.1
- Engines
- Count
- 1
- Name
- RS-68/RS-68A
- Placement
- core
- Count
- 2
- Name
- GEM 60
- Placement
- booster
- Count
- 1
- Name
- RL10B-2
- Placement
- upper
- First Flight Year
- 2,002
- Last Flight Year
- 2,019
- Manufacturer Id
- jd7aztg0m4tepcvsxqvs6fwv9d7kp30v
- Operator Id
- jd7aztg0m4tepcvsxqvs6fwv9d7kp30v
- Parent Vehicle Family Id
- nd7veg90vregh6hyz85x5dsvr985j89q
- Payload Capacity Kg
- Gto
- 6,160
- Leo
- 12,000
- Stages Count
- 2
- Strap On Boosters Count
- 2
Links
- Wikipedia Url
- https://en.wikipedia.org/wiki/Delta_IV
